Process Cooling Dry Air Coolers

Features

Performance range:

n  Capacity from 148 to 3212kW

(water, Tw1=40°C, Tw2=35°C, T1=25°C)

Fans:

n  Diameter Ø630, 800, 910, 1250, 1800mm, AC or EC motor.

Benefits:

n  Maximum performance, minimum footprint.

n  High efficiency geometry.

n  Modular design, 4~28 fans.

n  Piping in copper or stainless steel AISI 304 or AISI 316L.

n  Fins available in a wide range of materials.

Options:

n  Coil design refrigerant: water, oil, glycol, BC888, Shell S3X and S5X.

n  Multiple circuits.

n  Sub-cooling circuits.

n  Stainless steel or aluminum casing.

n  Epoxy resin aluminum or copper fins.

n  Explosion proof motor.

n  Customized fin spacing.
